On the Role of Stop Codons in the Genetic Code

John Cole

randoCode.py, switch.py, eigEx3.py

                 randoCode.py simply shuffles the wild type code some integer number of times.



                 switch.py takes as arguments a genetic code, and an integer i.  The script chooses from a uniform distribution an integer j between 0 and 63 inclusive, and swaps the amino acid specified as element i and the amino acid specified as element j in the genetic code.



                 eigEx3.py does essentially what eigEx2 does in terms of calculating the matrix M based on a genetic code and the relation table passed as arguments, but instead of solving the approximate eigenvalue problem outlined earlier, eigEx3.py simply returns the cleaved column from M associated with the stop codons.  This is later used in finding D and D².

Three short codes vital to the program.

randoCode.py:



import random



def randoCode(n):



#      [[1,phe],[2,leu],[3,iso],[4,met],[5,val],[6,ser],[7,pro],[8,thr],[9,ala],[10,tyr],[11,his],[12,glutamine],[13,asparagine],[14,lys],[15,aspartic],[16,glutamic],[17,cys],[18,trp],[19,arg],[20,gly]]



       code=[1,1,2,2,2,2,2,2,3,3,3,4,5,5,5,5,6,6,6,6,7,7,7,7,8,8,8,8,9,9,9,9,10,10,0,0,11,11,12,12,13,13,14,14,15,15,16,16,17,17,0,18,19,19,19,19,6,6,19,19,20,20,20,20]



       for i in range(n):

              random.shuffle(code)



       return code

switch.py:



import random

import numpy

def switch(code,i):

       j=numpy.copy(i)

       while i==j:

              j=random.randint(0,63)



       new=numpy.copy(code)

       new[i]=code[j]

       new[j]=code[i]



       return new

eigEx3.py:



import numpy

from numpy import linalg as LA



def eigEx(code,rel):



#      NRG=[302.0,-486.8,-520.6,-412.1,-466.1,-567.8,-373.3,-603.7,-415.9,-481.9,-221.8,-611.2,-590.5,-443.4,-786.7,-807.4,-378.1,-215.0,0.0,-390.0]



       M=numpy.zeros([21,21])

       for i in range(64):

              for j in range(9):

                     M[code[int(rel[0][i][j])]][code[i]]+=rel[1][i][j]



       vs=numpy.vsplit(M,[1,21])



       return vs[0]
